Electricial Info :

Light source: OSRAM SIRIUS HRI 461W;

Voltage: 110-240V, 50/60Hz;

Power: 650W ;

Channel mode: 18CHs ;

Display: full-color display screen can be inverted 180°;

Color disc: 14 color plates + white light;

Fixed pattern disc: 14 patterns + white light; One can flow pattern effect;

Prism: a prism consists of two prism discs;

Prism disc 1: 16 prism, Prism disc ii: 8+16+24 prism,

Exposure Angle: 2.1°;

Dimming: 0-100% mechanical dimming,

N/G.W : 24kgs/85kgs (double flycase packing)

Double Flycase Size : 89*46*88cm

support mechanical stroboscopic and adjustable stroboscopic effect,

support stroboscopic macro function,

lens group optical system Photoelectric reset system is adopted,

when misoperation occurs, it can be automatic retrieve reset;

Positioning technology: magnetoelectric positioning system is adopted to replace the traditional hall positioning system with magnetic devices,

with higher accuracy and reliable performance.

Level: 540°, resolution 8/16Bit;

Vertical: 270°, resolution 8/16 bit;

IP protection grade: IP65;
