SOL-WLED1240Z
Waterproof 12*40W 4-IN-1 LED Wash Moving Head Light IP65

Special point:

1. IP65/Waterproof, dustproof, oil resistant design, suitable for outdoor events

2. Each led is controllable individually , with ring circle around

3. With 3 phase motor on pan and tilt to make fast movement.

4. Professional designed housing to fit professional market.
Specification
Video
Specification
Video

Electricial Info :


Voltage range: AC100V-240V/50-60Hz

Rated power of the whole machine: 550W

Light source: 12 pieces × 40W RGBW LED High Brightness Imported Beads

Average lifespan: 50000hrs


Control mode: DMX512, RDM, master-slave mode

Channel mode: Built in 2 channel modes 22CH/74CH (standard mode


Scanning system: X stroke: 540 ° Y stroke: 216 °

Optical system: high-precision integrated structure lens, high transmittance quartz glass rod+PMMA lens

Optical angle: adjustable from 5 ° to 45 °


Beam beam: Outstanding small angle beam effect

Wash dyeing: evenly spread light at medium to large angles

Color: RGBW color mixing system, uniform color mixing without flicker, fast color rainbow effect

Adjustable color temperature: 2500-10000K

Effect macros: static effect macro function and dynamic effect macro function

Strobe: 1-25Hz electronic strobe and random multiple strobes

Dimming: Electronic dimming, 4 dimming modes

Zoom system: linear electric zoom

Lamp body size: 432 × 333 × 485mm

Carton size: 610 x 530 x 450mm

N/G.W: 22kgs/26kgs


More :

Front halo light strip: can be controlled at a single point, with the ability to freely chase and change color while running horses

Single circle control: The light source supports independent control of color change for both inner and outer single circles

Single point control: The light source supports individual independent control and color transformation

Display screen: 1.77-inch OLED screen, bilingual menu in Chinese and English, anti-interference photoelectric signal isolation system, waterproof intelligent touch key

Shell material: Latest second-generation structural waterproof design, metal die-casting aluminum shell and fire-resistant engineering plastic
