Electricial Info :

Voltage : 100–240 V, 50/60 Hz

Lamp: Original YODN HRI 280W

Color temperature: 8500K

Beam angle : 5° – 20°  , Zoom angle : 2.5 ° -10 °

Color wheel : 13 colors + open

Rotate Gobo wheel : 9 rotating , indexable and replaceable

Static Gobo wheel : 13 gobos + open

Two Prisms : prism 1: 8- facet circular prism ; prism 2: 6- facet linear prism , bilateral rotation

Dimmer/Shutter: 0-100% dimming and variable strobe effect

X/Y Movement : X : 540° , Y : 270°

Control channels: 16 / 24 CHs

Control mode: Standard DMX512, Automatic and Master/ slave mode

Brackets system : two Omega 1/4 tern brackets (to standard clamps)

Demisions : 590*365*385mm

N/G.W: 19 / 22.5kgs

Advantages :

1. Automatic Pan and Tilt repositioning by photoelectric repositioning system when accidentally knock out of place.

2. Superheat protection: Fan system automatically adjusts wind speed by circle temperature.

3. Power Saving Function: Remote lamp control: when the switch shuttered ,the lamp consumption can be reduced automatically.
